3RA2110-0JH15-1BB4 Siemens SIRIUS 3RA2110 Contactor, 24 V dc Coil, 3 Pole, 1 A, 0.25 kW, 1NO

Siemens Contactor_x000D_ The Siemens SIRIUS 3RA2110 series is 3-pole, 0.25kw contactor. It follows a direct-on-line 400VAC starting mechanism for running a motor. The contactor has been designed to be mounted onto a 60mm busbar systems. This device has an electrical coil voltage rating of 24VDC and a current rating of 1A. It is designed to tolerate the heavy inrush current while driving a motor._x000D_ Features and Benefits_x000D_ • Contactor size is S00_x000D_ • Electric shock resistance_x000D_ • Load feeder fuseless_x000D_ • Long life of 30M switching cycles_x000D_ • Operating temperature ranges between -20°C and 60°C_x000D_ • Short circuit protection_x000D_ • Spring-type terminal_x000D_ • Vibration resistant_x000D_ Applications_x000D_ • Electrical systems_x000D_ • Factory automation_x000D_ • Marine transportation_x000D_ • Mechanical engineering_x000D_ • Railway transportation_x000D_ Certifications_x000D_ • ATEX certified_x000D_ • CE certified_x000D_ • CSA certified_x000D_ • CSA certified_x000D_ • EAC certified_x000D_ • IEC 60068-2-27_x000D_ • IEC 60947-4-1_x000D_ • IP20 rating_x000D_ • UL listed
