| Type | 3RT1076-6NP36 |
| Type | S12 |
| No. of pins | 3-pin |
| Contact type | 3 makers |
| Nominal voltage | 1000 |
| Mounting type | Screw-fit |
| Connection | Terminal strip |
| Durability | 1000 0000 |
| IP rating | IP00 |
| Min. temperature | -25 |
| Max. temperature | +60 |
| Width | 160 |
| Height | 214 |
| Depth | 225 |
| Dim | (W x H x D) 160 x 214 x 225 mm |
| Content | 1 |
| RoHS-compliant | Yes |
| Rated operation power at AC-3, 400 V | 250 |
| Number of normally open contacts as main contact | 3 |
| Number of auxiliary contacts as normally open contact | 2 |
| Number of auxiliary contacts as normally closed contact | 2 |
| Rated operation current Ie at AC-3, 400 V | 500 |
| Rated operation current Ie at AC-1, 400 V | 610 |
| Rated operation current Ie at AC-4, 400 V | 430 |
| Rated operation power at AC-4, 400 V | 250 |
| Product type | Contactor |
