| Type | 3RT2536-1NF30 |
| Type | S2 |
| No. of pins | 4-pin |
| Contact type | 2 breakers |
| Mounting type | Snap-in |
| Durability | 1000 0000 |
| IP rating | IP20 |
| Min. temperature | -40 |
| Max. temperature | +70 |
| Width | 75 |
| Height | 114 |
| Depth | 130 |
| Dim | (W x H x D) 75 x 114 x 130 mm |
| Content | 1 |
| RoHS-compliant | Yes |
| Rated operation power at AC-3, 400 V | 22 |
| Number of normally open contacts as main contact | 2 |
| Number of normally closed contacts as main contact | 2 |
| Number of auxiliary contacts as normally open contact | 1 |
| Number of auxiliary contacts as normally closed contact | 1 |
| Rated operation current Ie at AC-3, 400 V | 41 |
| Rated operation current Ie at AC-1, 400 V | 70 |
| Rated control supply voltage Us at AC 50HZ | 83.0-155.0 |
| Rated control supply voltage Us at AC 60HZ | 83.0-155.0 |
| Rated control supply voltage Us at DC | 83-155 |
| Product type | Contactor |
