| Type | 3RV1011-1HA10 |
| Type | S00 |
| Amperage adjustment range (min.) | 5.5 |
| Amperage adjustment range (max.) | 8 |
| Adjustment range (amperage) | 5.5 - 8 A |
| Contact type | 3 makers |
| No. of pins | 3-pin |
| Switching voltage (max.) | 690 |
| Connection | Screw terminal |
| IP rating | IP20 |
| Depth | 81 |
| Width | 45 |
| Height | 90 |
| Dim | (W x H x D) 45 x 90 x 81 mm |
| Content | 1 |
| RoHS-compliant | Yes |
| Type | Circuit Breakers |
| Adjustment range | 5.50 V - 8.00 AA. |
| Type | 3RV1011-1HA10 |
| Operating voltage | |
| Width | 45 |
| Height | 90 |
| Depth | 75 |
| Rated operation power at AC-3, 400 V | 3 |
| Rated permanent current Iu | 8 |
| Number of poles | 3 |
| Rated operation power at AC-3, 230 V | 1.5 |
| Rated short-circuit breaking capacity lcu at 400 V, AC | 50 |
| Product type | Circuit breaker |
