MR3A16BVBN Key Instruments MR3000 Series Variable Area Flow Meter for Gas, 2 L/min Min, 30 L/min Max

Key Instruments Flow Meter_x000D_ The Key Instruments MR3000 series variable area flow meter measures the gas flow rate of 2L/min to 30L/min. This is a high tech, moulded, low cost manufactured from high impact polycarbonate. It can operate at pressures of 100psig and temperatures of 150°F (65°C). These economically designed units provide high-quality and accuracy when installing properly. The durability of the polycarbonate allows the flow meter to provide years of trouble-free service. It is supplied with scales in LPM and SCFH for air, or CCM and GPH for water._x000D_ Inclusions:_x000D_ Mounting brackets and built-in bezel._x000D_ Features and Benefits_x000D_ Pipe diameter range is 1/8 in_x000D_ Connection type is 1/8 NPT female_x000D_ Maximum operating pressure is 6.9bar_x000D_ Maximum operating temperature is 65°C_x000D_ high-quality construction_x000D_ 10:1 turn direct reading scales_x000D_ Monitor or control air and water flow_x000D_ Supplied with east to read 10:1 turn direct reading scales_x000D_ Fittings made of brass_x000D_ Seal material is VITON W/ stainless steel_x000D_ Applications_x000D_ It is use with air and water_x000D_ Ideally suited for OEM applications
