MX6G10XB Panasonic Spur Gearbox, 10:1 Gear Ratio

6W 60x60mm Panasonic 3 Series Intermediate Gearboxes_x000D_ Fitted between a Panasonic 3 Series motor and a gearhead of the same frame size_x000D_ Provides a further 10:1 speed reduction for a motor-gearhead combination_x000D_ The output shaft of the intermediate gearhead has a gearscrew to allow it to engage and drive the attached gearhead_x000D_ Note_x000D_ Panasonic 3 Series 6W Gearboxes can only be used with Panasonic 3 Series 6W Motors._x000D_ Panasonic 3 Series Motors and Gearboxes_x000D_ Panasonic 3 Series Motors, with identical mounting dimensions as the G Series, replace and offer the following benefits over G Series Motors:_x000D_ Grease-lubricated gearboxes_x000D_ 10000hr life_x000D_ Quiet operation_x000D_ Class B motor insulation_x000D_ A number of additional design changes include:_x000D_ A number of gearboxes with shorter gearheads_x000D_ Different motor shafts (non-interchangeable with G Series gearboxes)_x000D_ Note_x000D_ Panasonic 3 Series Motors can only be used with Panasonic 3 Series Gearboxes._x000D_ Approvals_x000D_ UL, CE and CCC
