518-4412 RS PRO Pressure Switch, 0bar Min, 4bar Max, Analogue Output, Relative Reading

RS PRO Gas, Liquid Relative Pressure Switch, Analogue 0 → 4 bar, 10 → 30 V DC, G1/4 process connection_x000D_ This RS PRO pressure switch can measure the pressure exerted by liquid and gaseous media from 0 bar to 4 bar. The sensor's case is made from 303-grade stainless steel, so it won't be corroded by contact with the gas or liquid being measured, or contaminate the medium._x000D_ It converts pressure into an analogue electrical signal of 4 mA to 20 mA, which is directly proportional to the pressure being measured. A 1/4-inch threaded connector physically connects the switch to the pressure chamber. Electrical connections are made using a two-wire output via cable gland and screw terminal or M12 connector. You can power the sensor with a DC voltage of between 10 V and 30 V._x000D_ You'll find this product can be used in temperatures from -20°C to +125°C. These characteristics make it suitable for use in a wide range of applications, including the medical, aviation, automotive, and marine fields._x000D_ Features and Benefits_x000D_ • Pressure switch_x000D_ • Measurement of gas and liquid media_x000D_ • Non front-flush mounting_x000D_ • Accuracy of ≤ 0.5%_x000D_ • Pressure reading range of 0 bar to 4 bar_x000D_ • Response time of ≤ 3 ms_x000D_ • Electrical connections using cable gland and screw terminal or M12 connector_x000D_ • Process connection made using G1/4 connector_x000D_ • Operational temperature range of -20°C to +125°C_x000D_ • Supply voltage of 10 V to 30 V DC_x000D_ • Analogue current output of 4 mA to 20 mA_x000D_ • Housing of stainless steel_x000D_ • IP rating of IP65_x000D_ RS PRO_x000D_ RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards_x000D_ they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.
