795-1113 RS PRO Incremental Encoder, 50 ppr, HTL Inverted Signal, Hollow Type, 12mm Shaft

RS PRO Incremental Encoder 50 PPR, Hollow Shaft_x000D_ This incremental encoder from RS PRO is used to detect the position, revolutions per minute and speed of shafts in industrial machinery. It can be used on any shaft with speeds of up to 6000 rpm (revolutions per minute) and a maximum temperature protection rating of +60°C. This makes it ideal for heavy-duty equipment in the manufacturing and construction industries._x000D_ The encoder features a rugged die-cast aluminium housing cap, so it will withstand harsh environments. Plus, it has a high Ingress Protection (IP) rating of IP65 meaning it's dust-tight and will resist low-pressure waterjets. High noise immunity ensures error-free communication so you can be confident of accurate readings. As the unit is a through-bore encoder, it can be mounted on any part of the shaft, ensuring flexibility for space-saving applications._x000D_ Features and Benefits_x000D_ • Current rating of 70 mA_x000D_ • Incremental encoder technology_x000D_ • IP65 rated_x000D_ • Operating temperature range of -20°C to +80°C_x000D_ • Maximum revolutions of 6000 rpm_x000D_ • Hollow shaft flange mounting type_x000D_ • HTL (High Transistor Logic) inverted output signal type_x000D_ • Overall depth of 44.5 mm_x000D_ • Overall width of 58 diameter mm_x000D_ • Resolution of up to 5000 PPR_x000D_ • Shaft diameter of 12 mm_x000D_ • Hollow shaft type_x000D_ • Supply voltage of 5 to 30 V DC_x000D_ • Switching frequency of 200 kHz
