LR2K0314 Schneider Electric Thermal Overload Relay - 1NO + 1NC, 5.5 → 8 A F.L.C, 8 A Contact Rating, 100 W, 250 V dc, 690

Schneider Electric Mini Thermal Overload Relays - LR2-K Range_x000D_ Schneider Electrics K thermal overload relays are adjustable from 0.11 to 11.5 A, they have been predominantly designed for use in applications that require motor protection._x000D_ This range of mini thermal overload relays feature compensated and phase failure sensitivity, the range also offers manual and automatic reset. Each overload relay has 3-poles and screw clamp terminals._x000D_ Features & Benefits_x000D_ • Commonly referred to by the range short name - LR2K_x000D_ • Easy maintenance checks, check the tightening of cables through conducting thermographic testing and checking the mechanical operation of the product through manually operating the test, reset and stop buttons_x000D_ • Direct mounting under a contactor is achievable_x000D_ • Standards - IEC 947, BS4941, VDE 0660, NFC63-650_x000D_ • Standards - CSA, UL, DEMKO, NEMKO, SEMKO, FIMKO, PTB_x000D_ Applications of a Contactor and Control Overload Relay_x000D_ • The majority of the time is to protect a motor_x000D_ • To detect both overload conditions and fault conditions to then announce trip command for a protective device_x000D_ • To deactivate a device whenever it pulls high current_x000D_ • Sometimes developed into microprocessor systems and solid-state electronics_x000D_ Schneider Electric LR2K0314 TeSys K Differential Thermal Overload Relay._x000D_ Application – Motor protection_x000D_ Compatible with LC7K, LP1K, LP4K, LC1K._x000D_ DC and AC Network._x000D_ Class 10A to IEC 60947-4-1._x000D_ Thermal protection adjustment 5.5 to 8 A._x000D_ Contacts 1 NO and 1 NC._x000D_ Phase failure sensitivity to IEC 60947-4-1._x000D_ Yellow trip indicator._x000D_ Screw clamp terminals._x000D_ Height 58 mm._x000D_ Width 45 mm._x000D_ Depth 65 mm._x000D_ Net weight 0.145 kg._x000D_ Standards._x000D_ IEC 60947 / VDE 0660, BS 4941, NF C 63-650._x000D_ IP2x to IEC 60529._x000D_ Fire resistance 850° to IEC 60695-2-1._x000D_ Shock resistance NO contact 10 Gn for 11 ms – to IEC 60068-2-27._x000D_ Shock resistance NC contact 10 Gn for 11 ms – to IEC 60068-2-27._x000D_ Vibration NO contact 2 Gn, 5 to 300 Hz to IEC 60068-2-6._x000D_ Vibration NC contact 2 Gn, 5 to 300 Hz to IEC 60068-2-6.
