PS61.XXAGPHKMXX Vega VEGAPULS 61 Series Radar Level Probe, Vertical, Plastic Body

VEGAPULS 61 Non-Contact Microwave Radar Level Transmitter_x000D_ IP66 rated_x000D_ Measuring range up to 10m_x000D_ Unaffected by temperature, vacuum, pressure, vapours, gases or density_x000D_ Non-contact measurement with microwave pulses_x000D_ Accurate to 5mm using Echofox technology_x000D_ Maintenance-free rugged design_x000D_ Display/adjustment in head via PLICSCOM module or VEGADIS 61 remote housing (both types not supplied with unit)_x000D_ 2-wire (20 to 36V loop powered) technology; HART protocol with universal commands_x000D_ Output signal: 0//4 to 20mA (HART)_x000D_ 3/4in. BSP mount_x000D_ Vessel pressure:; -1 to +3 bar_x000D_ Housing material: PBT_x000D_ Transducer material: PVDF_x000D_ Cable entries: 2 x M20_x000D_ Simple calibration and in-head display of echo curve_x000D_ Fully communicative built-in data and trend logging_x000D_ Note: PLICSCOM module and VEGADIS 61 remote housing available separately – see stock nos. 468-3514 and 468-3508 respectively_x000D_ Note_x000D_ This product must be licensed by the user and is supplied with a licensing application form. Licensing is free of charge. Users should contact RS Technical in case of difficulty and for clarification of requirements.
