00355-200K-C3-73X Tedea Huntleigh Low Profile Load Cell, 200kg Range, Compression Measure

Model 355 is a welded bending load cell manufactured in stainless steel. Hermetically sealed against moisture the Model 355 construction and polyurethane shielded cable enables the load cell to function in harsh environments while maintaining its operating specifications. The low profile, high accuracy and sealing makes this load cell highly suitable for applications such as low profile platforms, weighing and packing machines, conversion of mechanical scales and variety of other applications where sealed cells are required. The two additional sense wires feed back the voltage reaching the load cell. Complete compensation of change in the lead resistance due to temperature change and/or cable extension, is achieved by feeding this voltage into the appropriate electronics._x000D_ Capacities 5–500 kg_x000D_ Stainless steel construction_x000D_ Applications_x000D_ Low profile platforms_x000D_ Loss-in-weight feeders_x000D_ Marine and hybrid scales_x000D_ Belt weighers_x000D_ Food industry harsh environment
