750-555 Wago PLC I/O Module for use with 750 Series, 100 x 12 x 64 mm, Analogue, Micro 800

Wago PLC I/O Module_x000D_ The Wago I/O SYSTEM 750 series PLC I/O module has 4 analogue output channels. The analogue output module creates a standardised signal ranging between 0mA and 20mA or 4mA and 20mA. The output signal is electrically isolated and will be transmitted with a resolution of 12bits. This current analogue output module uses power derived from the field side (loop powered). These output channels have one common ground potential. It is used with 750 series._x000D_ Features and Benefits_x000D_ Remote I/O modular system for all the functions_x000D_ Makes it easier to connect all the I/Os_x000D_ Communication with PC and PLCs_x000D_ Colour codes according to type of signal_x000D_ DIN mounting_x000D_ Dimension are 100mm x 12mm x 64mm_x000D_ Operating temperature ranges between 0°C and 55°C_x000D_ Power is derived from the field side_x000D_ Applications_x000D_ Industrial automation_x000D_ Robotics_x000D_ Automobile industry_x000D_ Certifications_x000D_ ANSI/ESD S20.20:2014_x000D_ BS EN 61340-5-1:2007_x000D_ CE certified
